Details
Features:
AC input range selectable by switch
Protections: Short circuit/Overload/Over voltage/
Over temperature
Cooling by free air convection
Withstand 300vac surge input for 5 second
Built-in constant current limiting circuit
100% fu日load burn一in test
LED indicator for power on
Fixed switching frequency at 90KHz
Low cost,high reliability
2 years warranty
Output:
Power: 36V 5.9A 212W
Voltage ADJ. Range: 32-40V
Setup, Rise Time: 1000ms, 50ms/230VAC 1000MS,50ms/115VAC at Full load
Input:
Voltage Range: 90-132VAC/180-264VAC By Switch 254-370VDC
Frequency: 47-63HZ
Efficiency: 88%
Over load: 105-150% rated output power
Over Voltage: 41.4-46.8V
Working Temp: -20 to +50 degree
Working Humidity: 20-90% RH non-condensing
Authentication: UL CE CB
Size: 215*115*50mm
Weight: 0.95KG
